AutoQuant 200
AutoQuant 200 Excelus Biochemistry Analyzer
Fully Automated Clinical Chemistry Analyzer with 200 Tests/Hour Throughput
Biochemistry AnalyzersMeril Life Sciences
Fully Automated Biochemistry Analyzer with research empowered automation featuring accuracy, convenience, high precision, ease of operation, and flexibility
Product overview
Fully Automated Biochemistry Analyzer with research empowered automation featuring accuracy, convenience, high precision, ease of operation, and flexibility
Technical specifications
| throughput | 200 tests/hour ISE optional, 300 tests/hour |
| sample position | 45 |
| sample volume | 2-50 μL (Adjustable in 0.1 μL step) |
| reagent position | 45 for R1 and R2 |
| reagent counter | Reagent 1: 100-350 μL (Adjustable in 1 μL step), Reagent 2: 0 or 10-350 μL (Adjustable in 1 μL step) |
| mixing | Mixing by paddle or by aspiration-dispense of reagent/sample |
| reaction system | 60 (Reusable) |
| wash system | On board identity with 7 step washing system |
| optical system | Photometry |
| light source | Tungsten halogen lamp (12V 20 W) cooled with air option for auto on-off of lamp |
| wavelength | 8 filters (340, 405, 450, 510, 546, 578, 600, 670, 700 nm) |
| measurement range | 0-3.5 Abs |
| resolution | 0.0001 Abs |
| calibration | K-Factor, Linear (one, two and multi-point), Logit log, Spline, Exponential |
| working conditions | {"power_supply":"110/220 VAC, 50/60 Hz Max. Power 250 W","temperature":"15°C - 30°C","humidity":"40% - 85% free from water dew formation"} |
| operation system | Windows XP, Windows 7, Windows 8, Windows 10 or Write |
| dimensions | 735mm (L) x 523mm (W) x 420mm (H) |
| weight | Approx. 55 kgs |
Clinical scope
Procedures
- • Clinical Chemistry Testing
- • Biochemical Analysis
- • Photometric Assays
- • Automated Laboratory Testing
Indications & use cases
Clinical ChemistryBiochemistry AnalysisAutomated TestingPhotometryMulti-Parameter TestingLaboratory DiagnosticsISE Optional
